BLADE 166R (51 m)
Truck-Mounted Aerial Work Platform
What’s more, with complete roadability, it can travel to site without the requirement for additional permits, making the logistics of your project more simple.
- 166 ft max height
- 98 ft outreach
- 1,300 lbs payload
Technical Specifications
-
Working Range
- Max. working height
- 166ft (51m)
- Max. horizontal outreach
- 98ft (29.9m)
- Below grade reach
- 38ft (11.5m)
-
Workman Basket
- Cage dimensions (extended)
- 12ft 6in x 3ft 2in
- Cage capacity
- 1,300lbs (590kg)
- Cage rotation
- 180 degrees
- Turntable rotation
- 440 degrees
-
Carrier Vehicle & Stowed Dimensions
- Gross vehicle weight
- 44,000lbs (19,958kg)
- Front axle weight
- 15,100lbs (6,849kg)
- Rear axle weight
- 28,935lbs (13,125kg)
- Length in transport position
- 34ft (10.36m)
- Height in transport position
- 12ft 5in (3.79m)
- Chassis
- Freightliner 114SD
-
Set-Up
- Max. set-up inclination
- 2 degrees
- Compliance
- ANSI A92.2 / CSA C225
Our 166 ft Truck Mounted Aerial Work Platform offers unparalleled versatility for any site environment. Featuring an expansive side outreach of 98 ft, all wheel drive, and the ability to set-up in under 15 minutes, this MEWP is the most versatile machine in this height range. What’s more, with complete roadability, it can travel to site without the requirement for additional permits, making the logistics of your project more simple.
The workman basket is over 12 feet wide and has a weight capacity of 590 kg / 1,300 lbs. It also has a rotation range of 180 degrees which allows for complete flexibility when working on projects that are challenging to reach.
Rental Options
When performing work at heights, Blade Platforms aims to ensure the utmost safety at all times. This is why we offer operated Truck Mounted Aerial Work Platform rentals and bare rentals to suit your requirements.
If you are experienced in using Truck Mounted Aerial Work Platform platforms but don’t own the machinery itself we can remove the cost of that investment with our rental service.
Alternatively, our experienced operators can be hired with the machine. Utilize our expertise to ensure your project is completed with efficiency and success.
Purchase a Truck Mounted Aerial Work Platform
We also offer our 166 ft Truck Mounted Aerial Work Platforms for purchase. By purchasing one of these machines you have permanent access to some of the best machinery in the industry.
Talk to one of our experienced team today to discuss your requirements and pricing options.
Reach Diagram
Full working envelope
Full-reach access
With up to 166ft of working height and 98ft of horizontal outreach, the platform covers its full working envelope to keep crews productive across the job site.
- Max. working height
- 166ft (51m)
- Max. horizontal outreach
- 98ft (29.9m)
Benefits of Blade Platforms Truck Mounted Aerial Work Platforms
Large Workman Basket
15 min Truck Mounted Aerial Work Platform Set Up
Industries that use the 166 ft Truck Mounted Aerial Work Platform
Other models in the fleet
All trucksBLADE 157P (48 m)
Truck Mounted Aerial Work Platform
BLADE 187P (57 m)
Truck Mounted Aerial Work Platform
BLADE 187R (57 m)
Truck Mounted Aerial Work Platform
BLADE 210P (64 m)
Truck Mounted Aerial Work Platform
BLADE 243P (75 m)
Truck Mounted Aerial Work Platform
BLADE 243R (75 m)
Truck Mounted Aerial Work Platform
BLADE 295P (90 m)
Truck Mounted Aerial Work Platform
BLADE 295R (90 m)
Truck Mounted Aerial Work Platform
BLADE 336P (103 m)
Truck Mounted Aerial Work Platform
What our customers say
See what customers are saying about Blade Platforms on Google.
Frequently asked questions
WHAT IS THE MAXIMUM LOAD CAPACITY OF A 166 FT BOOM LIFE?
The maximum load capacity for a 166 ft Truck Mounted Aerial Work Platform can vary by the model. Blade Platforms’ has a cage capacity of 600lbs making it ideal for heavy loads. We strongly advise you to read our specification sheet before using any Truck Mounted Aerial Work Platform platform.
WHAT KIND OF TERRAIN CAN A 190 FT Truck Mounted Aerial Work Platform OPERATE ON?
Many 166 ft Truck Mounted Aerial Work Platforms are designed for rough terrain and can operate on uneven surfaces. If you know the project you are working on includes uneven terrain, we recommend sourcing a Truck Mounted Aerial Work Platform that has appropriate tires and stabilization features. If in doubt, speak to our team to get guidance on the best Truck Mounted Aerial Work Platform for you.
DO I NEED SPECIAL TRAINING TO OPERATE A 166FT Truck Mounted Aerial Work Platform?
Yes, to operate a 166 ft Truck Mounted Aerial Work Platform you must have specialized training from OSHA. This training ensures you know how to use a Truck Mounted Aerial Work Platform safely and how to look out for any hazards or handle emergency procedures. At Blade Platforms, you can lease a bare Truck Mounted Aerial Work Platform or lease one with an experienced operator depending on your requirements. Contact us to discuss your options.
